ineo+ 658

BACK

System Specifications

System memory (standard/max) 4,096 MB
System hard drive 250 GB (standard)
Interface 10/100/1,000-Base-T Ethernet; USB 2.0;
Wi-Fi 802.11b/g/n (optional)
Network protocols TCP/IP (IPv4 / IPv6); IPX/SPX; NetBEUI; AppleTalk (EtherTalk);
SMB; LPD; IPP; SNMP; HTTP
Frame types Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP
Automatic Document Feeder Up to 300 originals; A6-A3; 35-210 g/m²; Dualscan ADF
Printable paper size A6-SRA3; customised paper sizes;
banner paper max. 1,200 x 297 mm
Printable paper weight 52-300 g/m²
Paper input capacity (standard/max) 1,150 sheets/6,650 sheets
Paper tray input (standard) 1x 500 sheets; A5-A3; 52-256 g/m²;
1x 500 sheets; A5-SRA3; 52-256 g/m²
Paper tray input (optional) 1x 500 sheets; A5-A3; 52-256 g/m²;
1x 500 sheets; A5-A3; 52-256 g/m²;
1x 2,500 sheets; A4; 52-256 g/m²
Large capacity tray (optional) 1x 3,000 sheets; A4; 52-256 g/m²;
1x 2,500 sheets; A4-SRA3; 52-256 g/m²
Manual bypass 150 sheets; A6-SRA3; custom sizes; banner; 60-300 g/m²
Automatic duplexing A5-SRA3; 52-256 g/m²
Finishing modes (optional) Offset; group; sort; staple; punch; post insertion; z-fold;
centre-fold; letter fold; booklet
Output capacity (standard) Max. 250 sheets
Output capacity (optional) Max. 3,300 sheets
Stapling Max. 100 sheets or 94 sheets + 2 cover sheets (up to 209 g/m²)
Stapling output capacity Max. 1,000 sheets
Letter fold Max. 3 sheets
Letter fold capacity Max. 30 sheets; unlimited (without tray)
Booklet Max. 20 sheets or 19 sheets + 1 cover sheet (up to 209 g/m²)
Booklet output capacity Max. 100 booklets; unlimited (without tray)
Copy/print volume (monthly) Rec. 33,000 pages; Max. 200,000 pages¹
Toner lifetime Black up to 28,000 pages; CMY up to 26,000 pages
Imaging unit lifetime Black up to 150,000/600,000 pages (drum/developer);
CMY up to 105,000/600,000 pages (drum/developer)
Power consumption 220-240 V / 50/60 Hz; Less than 1,6 kW
System dimension (WxDxH) 615 x 693 x 961 mm (without options);
615 x 693 x 1,200 mm (with desk/tray)
System weight Approx. 113 kg (without options)

Printer Specifications

Print resolution 1,800 (equivalent) x 600 dpi; 1,200 x 1,200 dpi
Page description language PCL 6 (XL 3.0); PCL 5c; PostScript 3 (CPSI 3016); XPS
Operating systems Windows VISTA (32/64); Windows 7 (32/64);
Windows 8 (32/64); Windows 10 (32/64);
Windows Server 2008 (32/64); Windows Server 2008 R2;
Windows Server 2012; Windows Server 2012 R2;
Macintosh OS 10.x; Unix; Linux; Citrix
Printer fonts 80 PCL Latin; 137 PostScript 3 Emulation Latin
Print functions Direct print of PCL, PS, TIFF, XPS, PDF (v1.7), encrypted
PDF files and OOXML (DOCX, XLSX, PPTX); mixmedia and
mixplex; "Easy Set” job programming; overlay; watermark;
copy protection; carbon copy print
Mobile printing AirPrint (iOS), Mopria (Android), Google Cloud Print (optional), WiFi Direct (optional), Konica Minolta Print Service (Android), ineoPRINT (iOS/Android/Windows 10 Mobile); Mobile Authentication and Pairing (Android/iOS)

Printer Specifications (optional)

Print controller Embedded Fiery IC-416
Controller CPU CPU type @ 2.9 GHz
Memory/HDD 2,048 MB / 250 GB
Page description language Adobe PostScript 3 (CPSI 3020) PCL 6, PCL 5c
Operating systems Windows VISTA (32/64); Windows 7 (32/64);
Windows 8 (32/64); Windows 10 (32/64);
Windows Server 2008 (32/64); Windows Server 2008 R2;
Windows Server 2012; Windows Server 2012 R2;
Macintosh OS 10.x; Linux

Scanner Specifications

Scan speed (mono/colour) Up to 120/120 ipm in simplex
Up to 240/240 ipm in duplex
Scan resolution Up to 600 x 600 dpi
Scan modes Scan-to-eMail (Scan-to-Me), Scan-to-SMB (Scan-to-Home)
Scan-to-FTP, Scan-to-Box, Scan-to-USB, Scan-to-WebDAV;
Scan-to-DPWS, Scan-to-URL; TWAIN scan
File formats JPEG; TIFF; PDF; compact PDF; encrypted PDF; XPS;
compact XPS; PPTX
Optional: searchable PDF; PDF/A 1a and 1b;
searchable DOCX/PPTX/XLSX
Scan destinations 2,100 (single + group); LDAP support
Scan functions Annotation (text/time/date) for PDF; up to 400 job programs;
real-time scan preview

Copier Specifications

Imaging technology Laser
Toner technology Simitri® HD polymerised toner/Polymerised toner
Copy/print speed A4 (mono/colour) Up to 65/65
Copy/print speed A3 (mono/colour) Up to 32/32
Autoduplex speed A4 (mono/colour) Up to 65/65
1st copy out time A4 (mono/colour) 3.0/4.0 sec.
Warm-up time Approx. 22 sec. in mono; 35 sec in colour²
Copy resolution 600 x 600 dpi
Gradation 256 gradations
Multicopy 1-9,999
Original format A5-A3; custom sizes
Magnification 25-400% in 0.1% steps; auto-zooming
Copy functions Chapter; cover and page insertion; proof copy (print and screen); adjustment test print; digital art functions; job setting memory; poster mode; image repeat; overlay (optional); stamping; copy protection

Fax Specifications

Fax standard Super G3 (optional)
Fax transmission Analogue; i-Fax; Colour i-Fax; IP-Fax
Fax resolution Up to 600 x 600 dpi
Fax compression MH; MR; MMR; JBIG
Fax modem Up to 33.6 Kbps
Fax destinations 2,100 (single + group)
Fax functions Polling; time shift; PC-Fax; receipt to confidential box;
Receipt to e-mail/FTP/SMB; up to 400 job programs

User Box Specifications

Storable documents Up to 3,000 documents or 10,000 pages
Type of user boxes Public; Personal (with password or authentication); Group (with authentication)
Type of system boxes Secure print; Encrypted PDF print; Fax receipt; Fax polling
User box functions Reprint; combination; Download;
Sending (e-mail/FTP/SMB and Fax); Copy box to box

System Features

Security ISO15408/IEEE 2600.2 compliant (in evaluation); IP filtering
and port blocking; SSL2; SSL3 and TSL1.0/1.1/1.2 network
communication; IPsec support; IEEE 802.1x support; User
authentication; Authentication log; Secure print; Hard disk
overwrite (8 standard types); Hard disk data encryption
(AES 256); Hard disk mirroring (optional); Memory data auto
deletion; Confidential fax receipt; Print user data encryption;
Copy protection (Copy Guard, Password Copy) optional
Accounting Up to 1,000 user accounts; Active Directory support (user
name + password + e-mail + smb folder); User function
access definition; Biometric authentication (finger vein
scanner) optional; ID card authentication (ID card reader)
optional; Authentication by mobile device (Android, iOS)
Software store+find (opt.), convert+share (opt.), Personal Applications (opt.), Enterprise Suite (opt.), Data Administrator (user accounts

1 If the maximum volume is reached within a period of one year, then a maintenance cycle must be performed
2 Warm-up time may vary depending on the operating environment and usage

  • All specifications refer to A4-size paper of 80 gsm quality.
  • The support and availability of the listed specifications and functionalities varies depending on operating systems, applications and network protocols as well as network and system configurations.
  • The stated life expectancy of each consumable is based on specific operating conditions such as page coverage for a particular page size (5% coverage of A4). The actual life of each consumable will vary depending on use and other printing variables including page coverage, page size, media type, continuous or intermittent printing, ambient temperature and humidity.
  • Some of the product illustrations contain optional accessories.
  • Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
  • DEVELOP does not warrant that any specifications mentioned will be error-free.
  • All brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
